HJVD Extra Lower Impedance High Voltage Aluminum Electrolytic Capacitors

PDF Download

Features

Extra lower impedance with temperature range -55~+105°C
Load life of 2000~10000 hours
RoHS & REACH compliant, Halogen-free

Specifications

Temperature: -40°C ~ +105°C
Load life: 2000~10000hours
Voltage: 63~450V DC
Capacitance: 1 ~ 680uF
Tolerance: ±20% at 120Hz, 20°C
Size: 4x5.4, 5x5.4, 6.3x5.4, 6.3x7.7, 6.3x10.5, 8x10.5, 8x12.5, 10x10.5, 10x12.5
12.5x13.5, 12.5x16.5, 16x16.5, 18x16.5, 18x21.5mm

Drawing of Series HJVD
